Instruction Manual
1
Product Overview
3x SATA III ports
1x mSATA slot
LED and PIN Header LED
LED / Header Status
mSATA - Green LED
On: Drive is linked
Blinking: Accessing the drive
SATA LED 0-3 - Pin Headers
On: Drive is linked
Blinking: Accessing the drive
LED All - Pin Header
On: When any one of the 4 drives is linked
Blinking: When any one of the 4 drives is accessing
