Connection

One length of HDB15 male-to-female cable is

required to connect from the Video Splitter Input to a

computer’s VGA output. Multiple monitors should be

connected to the Video Splitter’s output port as

shown below.

Figure 1: ST122PRO Connection

Figure 2: ST124PRO Connection
