StarTech.com USB2DVIMM6 Instruction Manual

USB to DVI Video Adapter6ft. USB 2.0 to DVI External Multi Monitor Video Adapter Cable - Male/MaleUSB2DVIMM6Instruction Manual*Please ensure that the

7Using the Adapter in Extended or Mirror ModeBy default the USB2DVIMM6 will be setup as an extended display. To change the display as a mirrored/clon

8Configuring Displays from the Menu BarIf you have checked the “Show displays in menu bar” in the Display Preferences window, then you can configure dis

9SpecicationsBus InterfaceUSB 2.0Connectors1x USB type A1 x DVI-D maleVideo SignalDVI-D (digital only)Cable Length6ft.Built in Memory16MBMaximum Numb

10Technical SupportStarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions.

StarTech.com has been making “hard-to-find easy” since 1985, providing high quality solutions to a diverse IT and A/V customer base that spans m

FCC Compliance StatementThis equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of

iTable of ContentsIntroduction ... 1Packaging Contents...

1IntroductionPackaging Contents1 x USB2DVIMM6 video adapter•1 x Driver CD•1 x User Manual•System RequirementsProcessor: 1.2GHz or higher clock spee

2accept it, then click Next.Please wait while the 4. installation package copies the necessary files. Once completed, plug in the USB2DVIMM6 adapter to

3Mac OS XInsert the Driver CD (included) into the CD/DVD-ROM drive.1. Browse through the Driver CD and locate the “DisplayLink-OSX” 2. .dmg file. Doubl

4CongurationWindows 2000/XP/VistaTo configure the image being displayed by the monitor that is connected to USB2DVIMM6, right-click on a blank section

5Configure the secondary display by selecting it from the dropdown menu, then adjusting the desired settings:Using the Second Display in Extended ModeI

6Here, you can set the secondary display to act as an extension of the primary desktop, or as a mirror image that duplicates the contents on the prima
